Swirltop – 7 inch LCD Digital Magnetic Stirrer & Hot Plate

• LCD display for precise monitoring of speed and temperature for Magnetic stirrer & Hot plate.
• Built in PID Controller ensures the safe heating of the medium with overheating and protection.
• Max heating plate temperature 550°C.
• Glass ceramic work plate provides excellent chemical resistant performance and efficient heat transfer.

SWIRLTOP – LED Digital Magnetic Stirrer & Hot Plate
Code Product Workplate Size No. / Case
E11650 LCD DIGITAL Magnetic Stirrer & Hotplate with
support Rod & External Temperature Probe
18.4 x 18.4 cm 1
E11651 LCD DIGITAL Hotplate with support Rod &
External Temperature Probe
18.4 x 18.4 cm 1
E11652 LCD DIGITAL Magnetic Stirrer & Hotplate 18.4 x 18.4 cm 1
E11653 LCD DIGITAL Hotplate 18.4 x 18.4 cm 1
Spare Accessories
Code Product No. / Case
E11654 SS/Support Rod-Seven Inch 1
E11233 ETP – External Temeperature Probe 1

Descriptions

• LCD display for precise monitoring of speed and temperature for Magnetic stirrer & Hot plate.
• Built in PID Controller ensures the safe heating of the medium with overheating and protection.
• Max heating plate temperature 550°C.
• Glass ceramic work plate provides excellent chemical resistant performance and efficient heat transfer.
• External temperature control is possible by connecting the temperature sensor (PT 1000) with an accuracy at ±0.2°C.
• Digital speed control.
• Maximum Speed at 1500rpm.
• Outstanding brushless DC motor performance enables more stirring power.
• Two rotating knobs enable the easy and direct change of speed and temperature.
• HOT WARNING will flash when the work plate temperature is above 50°C or even the hot plate is turned off.
• Remote Function provides PC Control and data transmission via RS232 using 3rd Party Software.

Product spec

CE certified Yes

SPECIFICATIONS :

Code E11650 & E11652 E11651 & E11653
Voltage 220-240V 220-240V
Frequency 50-60 Hz 50-60 Hz
Motor Type Brushless DC Motor Brushless DC Motor
Maximum stirring capacity 20 L NA
Work plate dimensions diameter 184 x 184mm (7Inch) 184 x 184mm (7Inch)
Work plate material Glass Ceramic Glass Ceramic
Temperature range Room Temperature – 550°C,
Increment 1°C
Room Temperature – 550°C,
Increment 1°C
Overheating protection 580°C 580°C
Temperature control accuracy ±0.1°c ±0.1°c
Speed display LCD NA
Temperature display LCD LCD
Speed range 100 – 1500 rpm, resolution± 1rpm NA
Maximum magnetic bar (length) 80mm NA
Dimension 215x360x112mm 215x360x112mm
Weight 5.3kg 5.3kg
Permissible ambient temperature &
Humidity
5 – 40°C 5 – 40°C
Permissible relative humidity 80% 80%
Protection class IP21 IP21
