BIOFILL Bottle Top Filtration System

• BIOFILL Bottle Top Filtration System is available as a Full Assembly or as a bottle top Funnel. ABDOS BIOFILL Bottle Top Filtration Systems are disposable, sterile, vacuum operated systems for the sterile preparation of buffers, tissue culture media, microbiological media, and other biological fluids. Systems are available with asymmetric 0.1 µm, 0.22 µm & 0.45µm PES membranes. ABDOS PES membrane has low protein binding and is surfactant-free.
• BIOFILL Filtration system is designed for sterilization or clarification of aqueous laboratory fluids. The filters are gamma radiated & manufactured in clean room plant.
• The complete system is composed of a polystyrene filter funnel and receiver bottle, a SECURE grasp cap, and a vacuum
hose adapter. Systems are also available with 15 ml and 50 ml polypropylene centrifuge tubes.

BIOFILL Bottle Top Funnel

CodeProduct DescriptionFunnel capacity
Volume
GL Size/ThreadsFilter Pore
Size
Membrane
Diameter
No./case
P21101250ml Funnel Only with 0.2 um PES Membrane250 ml450.2 µm66 mm24
P21102500ml Funnel Only with 0.2 um PES Membrane500 ml450.2 µm66 mm24
P211031000ml Funnel Only with 0.2 um PES Membrane1000 ml450.2 µm90 mm24
P21104250ml Funnel Only with 0.1 um PES Membrane250 ml450.1 µm90 mm24
P21105500ml Funnel Only with 0.1 um PES Membrane500 ml450.1 µm66 mm24
P211061000ml Funnel Only with 0.1 um PES Membrane1000 ml450.1 µm90 mm24
P21107250ml Funnel Only with 0.45 um PES Membrane250 ml450.45µm90 mm24
P211081000ml Funnel Only with 0.45 um PES Membrane1000 ml450.45 µm90 mm24
P211091000ml Funnel Only with 0.45 um PES Membrane1000 m450.45 µm90 mm24

BIOFILL Bottle Top Filtration System

CodeProduct DescriptionFunnel capacity
Volume
Receiver
Capacity Volume
Filter Pore
Size
Membrane
Diameter
No./case
P21090250ml, 0.2µm High Flow PES Bottle Top Filter Full Assembly, Sterile250 ml250 ml0.2 µm66 mm12
P21091500ml, 0.2µm High Flow PES Bottle Top Filter Full Assembly, Sterile500 ml500 ml0.2 µm90 mm12
P210921000mL, 0.2µm High Flow PES Bottle Top Filter Full Assembly, Sterile1000 ml1000 ml0.2 µm90 mm12
P21093250ml, 0.45µm High Flow PES Bottle Top Filter Full Assembly, Sterile250 ml250 ml0.45 µm66 mm12
P21094500ml, 0.45µm High Flow PES Bottle Top Filter Full Assembly, Sterile500 ml500 ml0.45 µm90 mm12
P210951000ml, 0.45µm High Flow PES Bottle Top Filter Full Assembly, Sterile1000 ml1000 ml0.1 µm90 mm12
P21096250ml, 0.1µm High Flow PES Bottle Top Filter Full Assembly, Sterile250 ml250 ml0.1 µm66 mm12
P21097500ml, 0.1µm High Flow PES Bottle Top Filter Full Assembly, Sterile500 ml500 ml0.1 µm90 mm12
P210981000ml, 0.1µm High Flow PES Bottle Top
Filter Full Assembly, Sterile
1000 m1000 ml0.1 µm90 mm12
P2109950ml centrifuge Tube and Funnel , 0.2µm High Flow PES Membrane, Sterile50 ml50 ml0.2 µm40 mm24
P2110015ml centrifuge Tube and Funnel , 0.2µm High Flow PES Membrane, Sterile50 ml15 ml0.2 µm40 mm24

Descriptions

• BIOFILL Bottle Top Filtration System is available as a Full Assembly or as a bottle top Funnel. ABDOS BIOFILL Bottle Top Filtration Systems are disposable, sterile, vacuum operated systems for the sterile preparation of buffers, tissue culture media, microbiological media, and other biological fluids. Systems are available with asymmetric 0.1 µm, 0.22 µm & 0.45µm PES membranes. ABDOS PES membrane has low protein binding and is surfactant-free.
• BIOFILL Filtration system is designed for sterilization or clarification of aqueous laboratory fluids. The filters are gamma
radiated & manufactured in clean room plant.
• The complete system is composed of a polystyrene filter funnel and receiver bottle, a SECURE grasp cap, and a vacuum hose adapter. Systems are also available with 15 ml and 50 ml polypropylene centrifuge tubes.
• Filtration funnels are compatible with the Quick Connect pedestal system, a cradle ring for use with existing lab stands, & vacuum hose adapters. Quick-Connect pedestal offers one-time vacuum connection and one-handed operation. Quick
Connect Pedestal are sold separately.

Product spec

Sterile (Gamma Irridiatation)Yes
Quality management system – Medical DevicesYes
