Thermo Mix TFT – Precision Heating, Cooling & Mixing Solution
Magnetic Adhesion Blocks
ABDOS Thermo Mix uses magnetic adhesion technology for effortless swapping of blocks, allowing flexibility in sample handling and experimental workflows.
Precise Temperature Control
Temperature settings are programmable and calibrated to ensure uniform heating and cooling, maintaining optimal conditions for sensitive reactions.
Efficient Mixing
Advanced electronic speed control ensures stable shaking across a wide frequency range, delivering reproducible results for both small and large volumes.
Applications Across Life Sciences
Ideal for gene synthesis, protein denaturation, enzymatic reactions, bacterial culture growth, and other molecular biology or biochemistry procedures.
User-Friendly Operation
TFT display provides clear visualization of temperature and mixing parameters. Programmable interface allows for time, temperature, and mixing control tailored to specific protocols.
| Código | Producto | Speed | Lugares | N.º/Caso |
|---|---|---|---|---|
|
Thermo Mix – LCD Digital
|
||||
|
E11340
|
TFT Digital Thermo Mix with Heating and Cooling and Mixing with 1.5 ml Heating Block (E11346)
|
N/A
|
N/A
|
1
|
|
E11341
|
TFT Digital Thermo Mix with Heating and Cooling with 1.5 ml Heating Block (E11346)
|
N/A
|
N/A
|
1
|
|
E11342
|
TFT Digital Thermo Mix with Heating and Mixing with 1.5 ml Heating Block (E11346)
|
N/A
|
N/A
|
1
|
|
Accesorios de repuesto
|
||||
|
E11343
|
Heating Block, used for 0.2 ml / 96 well PCR plate
|
1500 rpm
|
96
|
1
|
|
E11345
|
Heating Block, used for 0.5 ml
|
1500 rpm
|
24
|
1
|
|
E11346
|
Heating Block, used for 1.5 ml
|
1500 rpm
|
24
|
1
|
|
E11347
|
Heating Block, used for 2.0 ml
|
1500 rpm
|
24
|
1
|
|
E11348
|
Heating Block, used for 5 ml (Round Bottom)
|
1500 rpm
|
8
|
1
|
|
E11358
|
Heating Block, used for 5ml (Conical Bottom)
|
1400 rpm
|
8
|
1
|
|
E11349
|
Heating Block, used for 15 ml
|
800 rpm
|
8
|
1
|
|
E11350
|
Heating Block, used for 50 ml
|
600 rpm
|
4
|
1
|
|
* Standard Block can not be changed.
|
* Additional Block to be purchased separately.
|
|||
Descripción
The ABDOS Thermo Mix Series delivers precise and efficient shaking and mixing with excellent temperature accuracy and uniformity, suitable for applications like gene synthesis, protein denaturation, enzymatic reactions, and bacterial growth. It features tool-free, quick-change blocks with magnetic adhesion, programmable settings, and three-point calibration for precise heating and cooling control.
Especificaciones
| Característica | E11340 || E11341 || E11342 |
|---|---|
| Voltage | 220–240V || 220–240V || 220–240V |
| Frequency | 50–60Hz || 50–60Hz || 50–60Hz |
| Functions | Heating, Cooling & Mixing || Heating & Cooling || Heating & Mixing |
| Adaptor Block Material | Aluminum || Aluminum || Aluminum |
| Rango de temperatura | Heating: RT–100°C || Cooling: 15°C – below RT || Heating: 25–110°C Cooling: 15°C – below RT Heating: RT–100°C |
| Temperature Setting Range | 0–100°C || –5–110°C || RT–100°C |
| Temperature Uniformity @ 20–45°C | ±0.5°C || ±0.5°C || ±0.5°C |
| Temperature Control Accuracy @ 20–45°C | ±0.5°C || ±0.5°C || ±0.5°C |
| Maximum Heating Rate | 5.5°C/min || 5.5°C/min || – |
| Maximum Cooling Rate | 5.5°C/min (100°C–25°C), 0.5°C/min (below 25°C) || 5.5°C/min (100°C–25°C), 0.5°C/min (below 25°C) || – |
| Mixing Frequency | 200–1500 rpm || NA || 200–1500 rpm |
| Mixing Orbit | 3 mm || NA || 3 mm |
| Programmable Programs | 9 || 9 || 9 |
| Overheating Protection | 150°C || 150°C || 150°C |
| Dimensions (W x D x H, mm) | 200 x 235 x 120 || 200 x 235 x 120 || 200 x 235 x 120 |
| Weight | 7.3 kg || 7.3 kg || 7.3 kg |
| CE Certified | Yes || Yes || Yes |
